CHCNAV I76/X13 GNSS receiver BeiDou B1 and QZSS L1C Compatible RTK GNSS Receiver with Integrated Full Wave Fence Antenna™ Technology

Enhance overall stakeout efficiency by 40% by utilizing CAD AR visual stakeout technology. This innovative solution seamlessly integrates base maps with augmented reality (AR) to facilitate precise path planning and real-time visualization.

Achieve exceptional accuracy with the advanced 4th generation air-medium GNSS antenna and iStar 2.0 technology. The i76 is capable of delivering a fixed RTK rate of over 96% in regions with high solar activity, ensuring consistent and reliable data.

Improve measurement precision by 30% with the cutting-edge 5th Gen Ultra-IMU. This feature includes automatic pole tilt compensation of up to 60°, guaranteeing accuracy within 3 cm without the need for manual initialization.

The i76 is a comprehensive system that integrates GNSS, IMU, and dual wide-angle cameras to offer a smooth surveying experience. It allows for real-time stakeout and measurement tasks with intuitive visual feedback for enhanced efficiency.

Experience ease of handling and portability with the compact i76, which weighs only 450g and fits in the palm of your hand. Its design is 40% lighter and 50% smaller than industry standards, making it ideal for field operations requiring mobility.

With the i76's IP68 rating and 2-meter drop resistance, it can withstand challenging environments. Its biomimetic structure and sapphire lens ensure durability, making it a reliable tool for demanding field conditions.

Technical Parameters:

Applications:

When it comes to high-precision positioning for various applications, the CHCNAV i76 RTK GNSS Receiver stands out as a reliable and advanced solution. Originating from China, this receiver is designed to meet the needs of professionals in industries such as surveying, mapping, construction, agriculture, and more.

Equipped with cutting-edge technology, the CHCNAV i76 combines IMU GPS capabilities with an Advanced RTK Engine to deliver accurate and reliable positioning data. Whether you are conducting land surveying, construction layout, or precision agriculture tasks, this receiver offers the precision and performance you need.

The i76 supports various positioning techniques, including Code Differential GNSS with horizontal accuracy of less than 0.25 meters and vertical accuracy of less than 0.50 meters. It also features QZSS support for L1 C/A, L1C, L2C, and L5 signals, enhancing the receiver's compatibility and reliability in different scenarios.

For static and fast static measurements, the i76 provides horizontal accuracy of 3 mm + 0.4 ppm and vertical accuracy of 5 mm + 0.5 ppm, ensuring precise results even in challenging environments. Additionally, the RTK functionality offers horizontal accuracy of 5 mm + 0.5 ppm and vertical accuracy of 10 mm + 0.8 ppm, making it ideal for real-time positioning applications.

Furthermore, the optional internal radio feature allows for seamless communication on frequencies ranging from 405–470 MHz UHF to FH915 Spread Spectrum, enabling efficient data transmission in the field.

With CE certification and a minimum order quantity of 1, the CHCNAV i76 RTK GNSS Receiver is a cost-effective solution priced at 1480 USD. Payment terms of 100% T/T make the purchasing process straightforward and convenient for customers.

In conclusion, whether you require precise AR measurements, reliable RTK capabilities, or advanced positioning technology, the CHCNAV i76 RTK GNSS Receiver is the go-to choice for professionals seeking high-performance solutions in a variety of applications and scenarios.
